Coated Wire Rope

Import, production and distribution of all types of coated tow wire in Kariz industrial equipment.
PVC coated tow wire for sale
Sale of polypropylene coated towing wire
Sale of polyamide coated towing wire
Selling nylon coated towing wire
Sale of coated tow wire for gym equipment
Selling coated tow wire 1.5 to 3
Selling coated tow wire 2 to 4
Selling coated tow wire 3 to 5
Selling coated tow wire 4 to 6
Selling coated tow wire 5 to 7
Selling coated tow wire 6 to 8

Due to the fact that wire ropes are produced in different variations and depending on different needs, each of them has unique applications in different industries. Therefore, these steel ropes must be ready to be used in any weather conditions and different chemical conditions. Therefore, the towing wires are made resistant to destructive factors such as water and humidity, chemicals, ultraviolet radiation of the sun, etc. There are different ways to perform this retrofitting, such as galvanizing in the form of hot galvanizing and cold galvanizing, or producing steel towing wires, etc. One of the cheapest and most productive methods of retrofitting is coating the towing wire or rope. Steel is made of polymer materials.

Coated tow wire:
In the tow wire industry, it uses nylon PA, vinyl PVC, Teflon FEP, polyurethane PU and polyethylene PE. The benefits of cable sheathing are many, but mainly relate to sealing in lubricants, increasing cable life, achieving a desirable aesthetic appearance, as well as keeping dirt and debris from contacting the cable strand itself and reducing safety concerns.

But beyond these benefits, the coating protects the cable from shock and stress, and also protects the spools from wear and tear and is easy to clean.

In addition, sheathed cables offer greater flexibility and adaptability to various environmental conditions, making them suitable for a wide range of applications in various applications. Sheathing materials can also provide varying levels of resistance to chemicals, moisture and temperature, thus increasing the overall performance and lifespan of the cable in practice.


The specific choice of coating material depends on application requirements such as temperature range, chemical exposure, and the need for UV protection. For example, Teflon or FEP coated cables are ideal for applications requiring high temperature resistance and low friction, while polyethylene coated cables are suitable for environments where shock and water are present.


In marine sectors, sheathed cables play an important role in ensuring the safety and reliability of various equipment and systems. Sheathed cable can be found in mooring lines, winch systems and lifting operations, where the steel rope must withstand harsh conditions, including exposure to salt water, extreme temperatures and heavy loads.


In robotics and automation, sheathed cables are essential to provide smooth and precise motion control in a variety of applications, such as pick and place machines, commonly found in large centers such as Amazon and Wafer. In addition, sheathed cable is a popular motion control choice on assembly lines and where automated manufacturing and warehousing takes place. Sheathed cable also helps reduce friction between the cable and coupled components such as the pulley system. In addition, coated cables can protect against contaminants such as dust, dirt, and debris, ensuring optimal performance and longevity of the cable system regardless of environmental conditions.


In interior design, coated cable is used in various applications such as room lighting, smart room, wall covering, stage equipment, lighting systems and special effects equipment. Covering materials not only protect against wear, but also help reduce unwanted noises and vibrations. In cases where visual aesthetics are an important functional requirement, coated cables can be produced in almost unlimited colors, allowing for better aesthetics and better visibility in low light conditions.
Sheathed cables have many advantages over their unsheathed counterparts, making them a popular choice for a wide range of applications.
What are the types of coating materials for coating the tow wire?

PA nylon sheathed cable
Nylon-sheathed cable, also known as polyamide PA-sheathed cable, is one of the most popular cable sheaths in the industry, and for good reason. For example, nylon sheathed cables have been shown to extend mechanical cable life by a factor of three. Secondly, nylon is also hard and durable. Its toughness and flexibility make it a suitable coating for cables in rotary applications, where the cables are guided on pulleys.

In some factories, it lubricates the under-extrusion of nylon, which further increases the life of the cable in rotating applications. This lubricant reduces bending stresses in the wire rope, promising longer cable life and overall mechanical system economy.
In push-pull applications, the nylon-coated cable, which is also impregnated with lubricant, reduces the friction in the push-pull assembly. This allows for less force to be required to activate the devices.

PVC vinyl coated cable
Like nylon, vinyl-coated cable materials are very common. However, unlike nylon, vinyl PVC is not as durable or flexible in applications where cables are wound on reels. When using vinyl on reels, due to the way the cable is processed, the coating does not adhere to its substrate the cable. In non-moving or static cable operations, where protection of the cable from the elements is important, it makes vinyl an ideal choice.
Despite its vulnerabilities to movement, vinyl-coated cable nevertheless has a wide range of practical applications. PVC extrusion has excellent performance in most environments. Combined with UV inhibitors, the vinyl-coated cable remains stable under excessive sunlight, making it suitable for open area applications.

In the following section, we discuss the chemical and physical properties of the three main types of coatings that are used to protect the tow wire:
Polyvinyl chloride PVC
Polypropylene PP
nylon polyamide
Of the three types, PVC is the most popular.
PVC
PVC is very popular due to its versatility, flexibility and low cost. Its operating temperature is between -30°F -35°C and 180°F 80°C with a hardness of 90.
Polypropylene
In cases where there are harsh and dangerous working conditions, polypropylene is the choice that can protect the wire rope against corrosion and chemical washing. In addition, it is resistant to impact and wear. Polypropylene is a hard, rigid, crystalline thermoplastic made from a propene monomer that is flexible and inexpensive.
Nylon
Nylon is extremely wear-resistant, which makes it ideal for use in cold environments. It is not as flexible as PVC, but it has excellent protection against corrosion and impact. It has excellent chemical resistance at temperatures between -65°F -54°C and 230°F 110°C and is available in a wide range of colors or can be clear.
What sizes of tow wire can be coated?
Thanks to the existence of advanced extruder machines, wire ropes can be coated in different types and sizes. The main application of coated wire ropes is in small sizes, which we will refer to below. Wire ropes in small sizes are mainly made by extruding, including 2 mm coating of different polymer materials. Of course, this value can be adjusted.
1.5 mm towing wire with 3 mm coating
2 mm towing wire with 4 mm coating
3 mm towing wire with 5 mm coating
4 mm towing wire with 6 mm coating
5 mm towing wire with 7 mm coating
6 mm towing wire with 8 mm coating
This size of wire rope is the most used in the coated wire industry.

What is the method of packing and sending coated wire ropes?

Coated tow wires are mainly offered to dear customers in 500 meter wooden spools and 1000 meter wooden spools. Of course, this collection has the possibility of sending with the sizes you want, from one meter to several thousand meters.
The shipping method is that after receiving the official order and completing the financial affairs, the goods are delivered to the customers request either at the warehouse in Tehran, or to send to the cities, to reliable carriers or intercity terminals, including A bus or a ride will be sent according to the customers request.
Kariz industrial equipment:
Kariz industrial equipment, which has placed transparency, quality, raising the level of technical information and preserving the environment at the forefront of all its affairs in the field of providing lifting and moving cargo services, is ready to provide European quality products Germany, Spain, Ukraine, Turkey and ..., East Asia Japan, South Korea, Malaysia, China and Iran, all of which are produced and inspected under the international standards of ASTM - DIN - GOST - JIS, announces to the community active in the industry.
It is hoped that we will take a positive step in the development of the industry of this region by offering products with quality.
